AMC-450R automated cryogenic biological sample storage system is a vapor-phase liquid nitrogen storage equipment with compact design.
Fully-automated with high efficiency SBS rack access and single tube retrieval; compatible with tubes of various specifications.
Dimensions (WDH): ≤1780(W)x2380(D)x 2650(H)mm
/≤5.84(W) x 7.81(D) x 8.69(H) ft
Weight ≤ 2250kg
Storage Capacity: Cryotubes: ≥114,900(0.5mL)
≥165,100(0.75mL)
≥78,600(1mL)
≥60,400(2mL)
Voltage/Frequency/Current: 220V / 50HZ / 16 A
Standby Power: ≤ 350W
Operating Power: ≤ 1200W
Installation Power: ≤ 3500W
Product Feature
Rack-cassette storage structure, support automated SBS rack access and compatible with tubes of various specifications.
Support automated SBS rack access and compatible with tubes of various specifications.
Modular functional components with easy maintenance, excellent insulation, compact, and large capacity, single tube retrieval.
Cryogenic protection for tube-picking area, dehumidification system minimizes frost formation.
Automatic liquid nitrogen replenishment with liquid level and temperature warning
Equipped with light-rail for multi-equipment connection to construct unmanned biobanks for efficient and precise sample delivery.
Built-in batch scanning and single tube scanning functions.
The system provides an open API interface to integrate data with LIS/HIS/CIS systems.
Offer GMP and scientific research modes with user friendly interface.
Support intelligent inventory management, optimizing storage space utilization.
